Smart lighting in old buildings: retrofit without dust and drilling
TL;DR: In my field tests, the fastest and cleanest path in an old building is a mix of smart retrofit bulbs (E27/GU10), stick-on wireless wall switches, and—where space allows—under-plaster relays. Choose a mesh standard (Zigbee/Thread) for thick walls, keep local control for reliability, and phase the rollout room by room.
Altbau specifics: check prerequisites
Before committing to a system, I always evaluate three things on-site. First, the condition of wiring: brittle insulation, cloth-sheathed conductors or unknown junctions are red flags—have an electrician inspect and document. Second, box depth: many old switch boxes are shallow (often less than 35 mm). Under-plaster modules need space and proper strain relief. Third, circuits and fusing: mixed neutral loops, shared circuits across rooms and missing RCDs complicate smart installs and must be clarified.
Respect the building fabric and potential heritage constraints: no chasing walls, no visible conduits if not allowed. For wireless, factor in attenuation from thick masonry, reinforced ceilings and tiled bathrooms. In my tests, 2.4 GHz mesh (Zigbee/Thread) penetrates adequately, while single-hop Wi‑Fi can be hit-or-miss in perimeter rooms.
Technology choice: systems and standards
Old buildings reward standards that are robust and interoperable. Here’s how I position them after hands-on trials across several flats.
| Property | Mesh (Zigbee/Thread/Z‑Wave) | Wi‑Fi/Bluetooth |
|---|---|---|
| Range & walls | ⭐⭐⭐⭐ Mesh repeaters via bulbs/sockets; Z‑Wave 868 MHz excels through masonry | ⭐⭐ Variable; single-hop, may need more APs |
| Power use | Low idle; good for many nodes | Higher idle per device; OK for a few lamps |
| Setup & cost | Needs bridge/border router; mid-price | No hub needed; cheapest bulbs abound |
| Future-proof | Thread/Matter rising; Zigbee mature | Matter-over-Wi‑Fi grows, vendor lock-in risk |
| Local control | Common with bridges; reliable automations | Often cloud-first; choose vendors with LAN APIs |
Bridge vs hubless: Bridges (e.g., Hue, Thread border routers) centralize updates, scenes and local routines. Hubless Wi‑Fi works but scales poorly and often leans on cloud. For old buildings, I prefer a bridge-backed mesh for stability and extended range.
- Bridges enable local, fast automations and better reliability
- Mesh devices extend coverage in thick-walled flats
- Unified updates and clean device management
- Extra hardware cost and another plug-in device
- Vendor ecosystems can limit flexibility if chosen poorly
- Migration to new standards requires careful planning
On local vs cloud: motion-triggered lights should not depend on the internet. I aim for local switching, with cloud added only for remote access. Interoperability gets better with Matter, but mixed Zigbee+Hue/Thread+Matter setups already work well in practice.
Retrofit paths without chasing walls
Smart bulbs (E27/GU10): my go-to first step. Replace existing lamps, keep legacy wiring untouched. Dimming, color temperature and scenes come instantly. Use wired power always on and re-map wall control to wireless switches to avoid cutting power to smart bulbs.
Surface-mount radio switches and adhesive wall transmitters add proper wall control without chiseling: they stick onto plaster or tile and talk to your bridge. I’ve had excellent results placing them near original switch spots.
Where there’s enough box depth and a neutral conductor, under-plaster modules (dimmer/relay) let you keep your classic luminaires and wired wall switches, while making the circuit smart. Confirm minimum/maximum loads and the box temperature rating.
No neutral? These options work
Plenty of old circuits are 2-wire at the switch. In that case I consider:
- 2-wire-capable dimmers/relays that bleed minimal current through the load. Some need a bypass at the lamp for LED stability—test in one room first.
- Battery-powered wireless wall switches: zero wiring, flexible placement, child’s play to install.
- Friends of Hue / EnOcean kinetic switches: batteryless, energy-harvesting, feel premium and work reliably with matching bridges.
Important: Always have an electrician verify compatibility, protective devices, and safe conductor routing—especially in junction-heavy old flats.
Scenes, zones and light quality planning
Good smart lighting is more than on/off. I map each room into zones: task (desk/kitchen worktop), ambient (ceiling/wall wash), and accents (shelves, art). Choose LEDs with CRI 90+ for natural colors and use warm dim profiles (e.g., 2700 K down to 2200 K) for evenings. Daytime routines can raise brightness and cool the tone, while presence and dusk sensors trim waste and improve comfort without touching a switch.
From my tests, a simple trio—ceiling light + floor lamp + shelf strip—covers 90% of scenarios when paired with two well-tuned scenes per room.
Phased rollout: room-by-room wins
Start with a thorough inventory and photos of existing switches and junctions. Shut off the correct breaker, label wires, and document circuits. Then implement a pilot room (often the hallway or living room) to test mesh range and automation stability. Adjust placements, channel selections, and naming conventions in the app for clarity (e.g., “Living – Ceiling”, “Living – Floor Left”). Finally, expand to adjacent rooms to extend the mesh naturally.
Safety, standards and privacy
Insist on VDE-compliant installation by a professional: confirm loads, dimmer compatibility, in-box temperature, and luminaire ratings. Old ceiling roses and brittle conductors are common; replace where necessary. For privacy and resilience, keep firmware up to date, use strong local admin passwords, and prefer local routines over cloud. Segment smart devices on a separate Wi‑Fi/VLAN if possible.
Budget and priorities
In practice, I budget per room and phase purchases. Start with rooms that benefit most—hallway, kitchen, living—then bedrooms. Balance initial outlay against running costs and maintenance.
| Property | Budget path | Premium path |
|---|---|---|
| Typical per-room cost | €60–120 (Wi‑Fi or basic Zigbee bulbs + 1 wireless switch) | €180–400 (Hue/Thread bulbs, sensors, kinetic switch) |
| Ongoing costs | Low; check idle draw of Wi‑Fi bulbs | Low; bridges add a few watts 24/7 |
| Expandability | Good, may hit limits on large Wi‑Fi nets | Excellent with mesh + bridge |
My recommendation: Mix-and-match: use Zigbee/Thread for backbone lamps and add occasional Wi‑Fi strips where decorative. Keep one bridge as the brain for local scenes and robust routines.
Try it now: curated picks and stores
Ready to test in your pilot room? Start with reputable ecosystems and accessories I’ve verified for old-building retrofits:
- [url="https://www.amazon.de/stores/PhilipsHue/page/70E215C2-95AD-4399-AE1A-4F6C289B83FF",name="Explore Philips Hue store",title="This link leads to the Philips Hue Amazon store"]
- [url="https://www.amazon.de/stores/innr/page/A5D10EEE-9066-4131-88B0-F79E731FB6C8",name="Discover Innr (budget-friendly Zigbee)",title="This link leads to the Innr Amazon store"]
- [url="https://www.amazon.de/stores/Govee/page/91946BFA-9DD9-44AB-BD3F-FE87D3BCCEC0",name="Browse Govee (ambient & strips)",title="This link leads to the Govee Amazon store"]
- help
Do I need to replace my wall switches?
No. Keep line power permanently on for smart bulbs and add wireless wall switches to avoid cutting power. If you want the original rocker feel, consider kinetic Friends of Hue or under-plaster modules where space and wiring allow.
- help
How do I fix poor wireless coverage through thick walls?
Add more mains-powered mesh nodes (bulbs, plugs) to act as repeaters, or choose Z‑Wave for 868 MHz propagation. Avoid Wi‑Fi-only bulbs deep inside; use a proper mesh bridge and place it centrally.
- help
What if a room has only two wires at the switch?
Use 2-wire-capable dimmers/relays with a compatible bypass, or go fully batteryless kinetic for the wall control and keep smart bulbs powered. Always have an electrician confirm safety and compatibility.
